SAP Engineering Control Center interface to CATIA V5
General Information
This product helps customers to integrate CATIA V5 into SAP PLM. The interface allows to store CAD files in SAP’s Document Info Record and document structures. The product provides additional menu entries in the CAD system and connects the CAD system with SAP Engineering Control Center.
Preconditions
SAP Engineering Control Center needs to be installed and configured. Please refer also corresponding documentation and installation guides for SAP Engineering Control Center.
Procedure
Please download the software to your local client, start the installer and follow the instructions.
Relevant SAP Notes
What Is Catia Plm Express
- SAP Note 2572830 (Installation Prerequisites)
- SAP Note 2123783 (FAQs)
- SAP Note 2179197 (Logging)
- SAP Note 2178935 (Patch Notes 1.0.2.0)
- SAP Note 2196747 (Patch Notes 1.0.3.0)
- SAP Note 2283087 (Patch Notes 1.1.x)
Documentation
The documentation can be found in the SAP Help Portal.Please search for term: catia
Product Availability Matrix (PAM)
| Release SAP Engineering Control Center interface to CATIA V5 | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 1.0.0 | 1.1.0 - 1.1.3 | 1.1.4 | 1.1.5 | 1.1.6 | 1.1.7 | 1.1.8 | 1.1.9 | ||
| SAP Engineering Control Center | 5.0 | X | - | - | - | - | - | - | - |
| 5.1 / 1.0 for SAP HANA | - | X | X | X | X | X | X | X | |
| 5.2 / 1.1 for SAP HANA | - | - | - | - | - | - | X | X | |
| CAD System | CATIA V5-6 R2012 (R22) | X | - | - | - | - | - | - | - |
| CATIA V5-6 R2013 (R23) | X | X | - | - | - | - | - | - | |
| CATIA V5-6 R2014 (R24) | X | X | - | - | - | - | - | - | |
| CATIA V5-6 R2015 (R25) | - | X | X | X | - | - | - | - | |
| CATIA V5-6 R2016 (R26) | - | X | X | X | X | X | - | - | |
| CATIA V5-6 R2017 (R27) | - | - | X | X | X | X | X | X | |
| CATIA V5-6 R2018 (R28) | - | - | - | - | X | X | X | X | |
| CATIA V5-6 R2019 (R29) | - | - | - | - | - | - | X | X | |
| Operating System | Windows 7 64 bit (*) | X | X | X | X | X | X | X | X |
| Windows 8.1 64bit (only for R24 or higher) (*) | - | X | X | X | X | X | X | X | |
| Windows 10 64bit (only for R26 SP3 or higher) | - | X | X | X | X | X | X | X | |
(*) Windows 7 and 8.x are only supported by SAP ECTR 5.1. SAP ECTR 5.2 and 1.1 (for SAP HANA) support Windows 10 only.
Prerequisite 1.0.0:
- Microsoft Visual C++ Runtime in version 2005 und 2008
- .net Framework 3.5
Prerequisite 1.1.0
- Microsoft Visual C++ Runtime in Version 2008 including the following updates:
- Microsoft Visual C++ 2008 Service Pack 1 Redistributable Package ATL Security Update
- Microsoft Visual C++ 2008 Service Pack 1 Redistributable Package MFC Security Update
- Microsoft Visual C++ 2008 Service Pack 1 Redistributable Package ATL Security Update
- .net Framework 3.5
Maintenance Strategy
SAP plans to ship minor releases on a regular basis. Additionally we plan to deliver Support Packages and Feature Packages on a regular basis.
SAP recommends always installing the latest Support Packages and Feature Packages.
A Support Package will contain corrections; Feature Packages will contain new functionality.
Support
In case you encounter problems when installing, upgrading or running SAP Engineering Control Center interface to CATIA V5, report an incident using component PLM-ECC-CAT.
Additional Information
Additional information about licensing can be found in SAP Note Note 1299572 and 2058039.
